"YOCH Pillow (plummer) block ball bearing units consist of an insert bearing mounted in a housing, which can be bolted to a support surface. The YOCH assortment includes units compliant with ISO standards, North American standards, or Japanese Industrial Standards (JIS). Within the assortment, you can find units for nearly all requirements. In addition, YOCH Food Line ball bearing units provide hygienic and high-performance bearing unit solutions for the most demanding food and beverage environments."
Type | Shaft | Dimensions in mm | Weight | ||||||||||
-∅ | (kg) | ||||||||||||
in mm | h | a | e | b | S2 | S1 | g | w | Bi | n | ds | ||
UCP305 | 25 | 45 | 175 | 132 | 45 | 20 | 17 | 16 | 85 | 38 | 15 | M14 | 1,6 |
UCP306 | 30 | 50 | 180 | 140 | 50 | 20 | 17 | 19 | 95 | 43 | 17 | M14 | 2,1 |
UCP307 | 35 | 56 | 210 | 160 | 56 | 25 | 17 | 21 | 105 | 48 | 19 | M14 | 2,8 |
UCP308 | 40 | 60 | 220 | 170 | 60 | 27 | 17 | 23 | 116 | 52 | 19 | M14 | 3,6 |
UCP309 | 45 | 67 | 245 | 190 | 67 | 30 | 20 | 25 | 128 | 57 | 22 | M16 | 4,7 |
UCP310 | 50 | 75 | 275 | 212 | 75 | 35 | 20 | 28 | 143 | 61 | 22 | M16 | 6,4 |
UCP311 | 55 | 80 | 310 | 236 | 80 | 38 | 20 | 31 | 154 | 66 | 25 | M16 | 7,8 |
UCP312 | 60 | 85 | 330 | 250 | 85 | 38 | 25 | 33 | 165 | 71 | 26 | M20 | 9,4 |
UCP313 | 65 | 90 | 340 | 260 | 90 | 38 | 25 | 36 | 174 | 75 | 30 | M20 | 10,3 |
UCP314 | 70 | 95 | 360 | 280 | 90 | 40 | 27 | 40 | 186 | 78 | 33 | M22 | 11,9 |
UCP315 | 75 | 100 | 380 | 290 | 100 | 40 | 27 | 40 | 197 | 82 | 32 | M22 | 14,5 |
UCP316 | 80 | 106 | 400 | 300 | 110 | 40 | 27 | 45 | 209 | 86 | 34 | M22 | 17,1 |
UCP317 | 85 | 112 | 420 | 320 | 110 | 45 | 33 | 45 | 221 | 96 | 40 | M27 | 19,2 |
UCP318 | 90 | 118 | 430 | 330 | 110 | 45 | 33 | 50 | 233 | 96 | 40 | M27 | 21,1 |
UCP319 | 95 | 125 | 470 | 360 | 120 | 50 | 36 | 50 | 250 | 103 | 41 | M30 | 28,2 |
UCP320 | 100 | 140 | 490 | 380 | 120 | 50 | 36 | 55 | 275 | 108 | 42 | M30 | 34,8 |
UCP322 | 110 | 150 | 520 | 400 | 140 | 55 | 40 | 60 | 295 | 117 | 46 | M33 | 43,2 |
UCP324 | 120 | 160 | 570 | 450 | 140 | 55 | 40 | 70 | 321 | 126 | 51 | M33 | 54 |
UCP326 | 130 | 180 | 600 | 480 | 140 | 55 | 40 | 50 | 355 | 135 | 54 | M33 | 72,1 |
UCP328 | 140 | 200 | 620 | 500 | 140 | 55 | 40 | 60 | 393 | 145 | 59 | M33 | 91,2 |
