Published by YOCH Bearing at 26/06/2023

Categories

Date26/06/2023

Deep groove ball bearings mainly bear radial load, but also can bear radial load and axial load. When it is only under radial load, the contact Angle is zero. When the deep groove ball bearing has a larger radial clearance, it has the performance of angular contact bearing and can withstand larger axial load. The friction coefficient of deep groove ball bearing is very small and the limit speed is very high.

The basic type of deep groove ball bearing consists of an outer ring, an inner ring, a group of steel balls and a group of cages. There are two types of deep groove ball bearing, single row and double row, deep groove ball structure is also divided into sealed and open two kinds of structure, open refers to the bearing without sealing structure, sealing type deep groove ball is divided into dust seal and oil seal. The dust proof sealing cover is made of steel plate stamping, which only prevents dust from entering the bearing raceway. The oil-proof type is contact oil seal, which can effectively prevent the grease spillover in the bearing.

Model d mm D mm H mm W kg Dynamic Static

6300 10 35 11 0.053 8200 8200

6301 12 37 12 0.06 9750 9700

6302 15 42 13 0.082 11400 11400

6303 17 47 14 0.115 13600 13600

6304 20 52 15 0.142 15900 15900

6305 25 62 17 0.232 23600 20600

6306 30 72 19 0.346 26700 26700

6307 35 80 21 0.457 33500 33500

6308 40 90 23 0.639 40700 40500

6309 45 100 25 0.837 53000 53000

6310 50 110 27 1.082 62000 62000
