TIMKEN Factory Bearings 15126/250 Tapered Roller Bearing

Structure:

This type of bearing is equipped with a round platform roller, the roller by the inner ring of the large rim.
Single row bearings can bear radial load and unidirectional axial load, and double row bearings can bear radial load and bidirectional axial load.Suitable for bearing heavy load and shock load.
According to the different contact Angle (α), it can be divided into three types: small cone Angle, middle cone Angle and large cone Angle. The larger the contact Angle is, the greater the axial load capacity is.
Outer ring and inner assembly (inner ring and roller and cage assembly) can be separated for easy assembly and disassembly.

Size range:
Single row tapered roller bearings:
Inner diameter size range: 20mm ~ 1270mm
Outer diameter size range: 40mm ~ 1465mm
Width: 15mm to 240mm

Double row tapered roller bearings:
Inner diameter size range: 38mm ~ 1560mm
Outer diameter size range: 70mm ~ 1800mm
Width size range: 50mm ~ 460mm

Four row tapered roller bearings:
Inner diameter range: 130mm ~ 1600mm
Outer diameter size range: 200mm ~ 2000mm
Width range: 150mm ~ 1150mm
