22/05/2024Factory Directly Selling TIMKEN 32010 Tapered Roller Bearing
21/05/2024
Main applications of taper roller bearing：
Front wheel, rear wheel, transmission, differential pinion shaft. Machine tool spindles, construction machinery, large agricultural machinery, railway vehicle gear reducer, rolling mill roller neck and reducer.
Tapered roller bearings are separated bearings, and the inner and outer rings of the bearings have tapered raceways. This kind of bearing is divided into single row, double row and four row tapered roller bearings and other different structural types according to the number of rows of rollers installed.
Single row tapered roller bearings can bear radial loads and single direction axial loads. When the bearing bears radial load, an axial component will be generated, so it needs another bearing that can bear the axial force in the opposite direction to balance it.
How to install tapered roller bearings?
Adjusting axial clearance For the installation of tapered roller bearing axial clearance can be adjusted by adjusting nuts on the journal, adjusting gaskets and threads in the bearing seat hole, or by pre-tightening springs and other methods. The size of axial clearance is related to the arrangement of bearing installation, the distance between bearings, the material of shaft and bearing seat, and can be determined according to working conditions.
For tapered roller bearings with high load and high speed, the influence of temperature rise on axial clearance must be considered when adjusting clearance, and the reduction of clearance caused by temperature rise must be estimated. That is to say, the axial clearance should be properly adjusted to a larger extent.
For bearings with low speed and bearing vibration, no-clearance installation should be adopted, or pre-load installation should be applied. The purpose is to make the tapered roller bearing roller and raceway have good contact, uniform load distribution, prevent the roller and raceway from vibration impact damage. After adjustment, the size of axial clearance is tested with a micrometer.
