Angular Contact Ball Bearings:
Angular contact ball bearings can bear radial load and axial load at the same time.Able to work at high speed.The higher the contact Angle, the higher the axial bearing capacity.The contact Angle is the Angle between the contact line of the ball and raceway in the radial plane and the vertical line of the bearing axis.High precision and high speed bearings are usually 15 degrees of contact.The contact Angle will increase under axial force.
Main applications of angular contact ball bearing:
Papermaking machinery, reducer, railway vehicle axle, rolling mill gearbox bearing seat, rolling mill roller, crusher,vibrating screen, printing machinery, woodworking machinery, all kinds of industrial reducer, vertical self-aligning bearing with seat,elevator wheel.
Single row angular contact ball bearings can only withstand axial load in one direction. When such bearings are subjected to pure radial load, they must be installed and used in pairs because the line of action of the rolling body load and the line of action of the radial load are not in the same radial plane, resulting in an internal axial component.
Single row angular contact ball bearings can only withstand axial load in one direction. When such bearings are subjected to pure radial load, they must be installed and used in pairs because the line of action of the rolling body load and the line of action of the radial load are not in the same radial plane, resulting in an internal axial component.
