Product Name |
SKF High Speed 6206 2Z Deep Groove Ball Bearing |
|
Material |
Chrome Steel/Gcr15 |
| Seal Type |
Iron Seal |
|
Number of row |
Single Row |
|
Inside Diameter |
30mm |
|
Outside Diameter |
62mm |
|
Thickness |
16mm |
|
Weight |
0.199kg |
| OEM |
Available |
Iron Seal Bearings
Rubber Sealed Bearings
Open Sealed Bearings
ZZ type ---- Bearing is sealed by steel on both sides.
Advantages: High speed,has a good dust effect. Disadvantages: Can not prevent the intrusion of liquid debris.
Advantages: High speed,has a good dust effect. Disadvantages: Can not prevent the intrusion of liquid debris.
2RS type ---- Bearing is sealed by black, blue or other colful rubber on both sides.
Advantages:To prevent any foreign intrusion,super dust effect. Disadvantages: The price is relatively high,the general speed.
Advantages:To prevent any foreign intrusion,super dust effect. Disadvantages: The price is relatively high,the general speed.
Open type ---- Bearing comes without seal on any side.
Advantages:High speed,idling effect . Disadvantages: Dust effect is poor,easy into the dust,impurities and so on.
Advantages:High speed,idling effect . Disadvantages: Dust effect is poor,easy into the dust,impurities and so on.
Bearing Description
Bearing Component
Bearing Characteristics
It consists of an outer ring, an inner ring, a set of steel balls and a set of cages.
It mainly bears pure radial loads, but also can bear joint loads. When it is subjected to pure radial load, its contact Angle is zero. When it has a larger radial game, that is, it has angular contact bearing performance, which can withstand a larger axial load.
Deep groove ball bearing simple structure, compared with other easy to achieve high precision, so can be mass production. In addition to the conventional models, it also has a variety of structural variations, such as deep groove ball bearing with dust cover, deep groove ball bearing with rubber ring and deep groove ball bearing with a stop groove and so on.
